Yandoit Case Study

‍

In this article we look at what options are available to a nursery looking to expand operations, negate its reliance on grid power and cope with ever increasing  brownouts and blackouts which is all part of a T.E.M.S. approach ( total energy management strategy).

‍

‍

The challenge and the reason for putting in solar

‍

The problem that they constantly were encountering was an inconsistent power supply. Brownouts and blackouts are common in the area, and Dan was aware that this was having a significant impact on his lifestyle and business.

‍

Next steps

‍

Dan engaged Greenwood to look over his existing electrical infrastructure to see how we could help with his energy needs to give consistent supply as he is on a SWER ( single wire earth return) line.

‍

Critical loads

‍

There is a 10A bore pump, 2 X 9.5A water pumps, 8A UV water treatment pump that all play a critical role in delivering enough clean water, via a complex irrigation system, to where needed.

In addition to the above there were all the standard house loads;  3  x split AC system which were 9 amps each and all the usual appliances including washing machine and an oven.

‍

‍

Pre site visit

‍

Before we went to site, Veli, our CEC accredited battery off-grid specialist, asked Dan a series of questions that helped ascertain what we were actually dealing with, what expectations Dan and Jenny had and what could be realistically achieved.

‍

The solution

‍

Pat, Chief A Grade at Greenwood, arrived at the site and performed an energy audit that identified all the site loads on the property, how long they were on for per day and how we could integrate as much solar as possible to handle their particular load profile, a standard house and business, in addition to calculate the required storage component given the electrical infrastructure.

With any PV system, you need to be aware of the voltage of the incoming supply and how the system will perform based on what services are on site.

‍

The recommendation

‍

Pat's recommendation was to install solar on the main shed but with an orientation of North South, we needed to come up with a solution that provided the most amount of energy production to service the considerable day time loads, charge the batteries for their night time duties and still have enough storage component to cope with the frequent brownouts and blackouts.

‍

The system

‍

Greenwood designed a system that consisted of:

• 10.8kW of solar on the North roof with
• 1 X Fronius 8.2kW Primo Inverter flush mount, and
• 8.2kW of solar on the south roof, on tilt facing NW utilising a
• 6kW Fronius Primo Inverter
• 2 x Tesla Powerwall 2 Energy storage systems

‍

‍

Each side of the roof runs off to its own Tesla Powerwall 2 w / Gateway.

‍

The result

‍

The PV system will produce on average, 68kWh of renewable energy per day. If power is lost to the property, the batteries will kick in and maintain critical loads. The system has also been designed so that any power that is not needed for the critical loads will go into assisting with his night time load to reduce his overall energy spend.

The system offers long term reliable energy needs for the property and also offers flexibility through the Tesla Gateway as the business ramps up.

‍

Backup storage in the bush

• 18.5kW Photovoltaic System
• Canadian Solar 370W HiKU Tier 1 Panels
• 1 X Fronius 8.2kW Primo 1PH Inverter
• 1 X Fronius 6.0kW Primo 1PH Inverter
• 2 X Tesla Powerwall 2 13.5kWh (27kWh total) w / Gateway and monitoring
